Linear guide high accuracy CNC 6040 4 axis | cnc machine metal | stainless steel cnc | cnc spindle 2.2kw
- It can work with 3 axis / 4 axis
- Integrated high-speed micro computer intelligent control chip.
- First STEEL STRUCTURE CNC6040 in the Market
- Mach 3 software, supports Win10
- Built in frequencey converter and without controller box
- Applicable to steel, aluminum, brass, copper, stone, granite etc.
Higher precision because:
- Heavier steel structure
- XHC control boad
- With auto-checking function.
- 2200w water-cooled spindle.
- Ball screw
You can buy this machine from us without any worry because:
- CE approved.
- Video support.
- English manual available.
- Mach 3 software send with the machine as a CD.
- Can engrave material which hardness below 45.
- From reliable & trustable profesional China CNC Router manufacturer
Technical detailes for this CNC 6040 4 axis | cnc machine metal | stainless steel cnc | cnc spindle 2.2kw high accuracy
|Model||4 Axis CNC Machine|
|Effective work area||
|X rail material||
Dia.30mm chrome plate shafts
|Y rail diameter||
Dia.20mm chrome plate shafts
|Z rail diameter||
Dia.16mm chrome plate shafts
|XYZ axis torque||
57 two-phase 2.5A 55N.cm
|Repeat positioning accuracy||0.01mm|
|Processing speed||0-4000 mm/Min|
|A-axis B-axis rotation speed||0-180 rpm/min|
|Tailgate material||Stainless steel|
|Switching Power Supply||Integrated 24V 350W|
|Spindle power||2200W water-cooled frequency spindle|
|Input Power||220V / 110V power supply|
|Output Current||Drive 4.5A (peak 5A)|
|Drive motor||57*42 stepper motors (two-phase 4 wire)|
CNC 6040 4 axis | cnc machine metal | stainless steel cnc | cnc spindle 2.2kw high accuracy Packing list
We provide DHL, TNT, Fedex, Special lines, DDP (Delivered Duty Paid), Sea shipping and Air shipping.... The shipping ways we choose is depends which country you are and what machine model you choose, if you have special shipping requirements please kindly contact us first.
If you are from the following countries, here are some information you need to read first.
USA, Canada: When you order a machine over 68KG, better leave a shipping address which belongs to business zone, if ship to residential area, there may cause some dispatching fees, or you can confirm shipping cost from us first then place an order.
Russia: We have special line service to Russia with all tax and duty included, so the shipping time maybe longer, maybe around 28-35 days arrival, so when you need this machine urgently, kindly let us know in advance.
Turkey: Need to import under a name of company which can do custom clearance, no personal orders.
Brazil, Argentina: You must make sure you can do custom clearance at first.
EU:Most of EU countries we provide door to door with all tax and duty included service, we have warehouse in Germany, so when your machine model is available in our Germany warehouse, then we can ship directly from Germany, if out of stock, we may use train shipping ways, this way may be slow, around 30-50 days arrival. if you requires fast shipping, please kindly let me know.
